XD-COB 320*160 Channel Module Selling Points:
Fully inverted LED chips, no residual images, no
"moth" effect, low power consumption.COB
packaging, dustproof, moisture-proof, surface
hardness of 4H, washable.
| Pixel Pitch | 1.25mm | 1.53mm | 1.86mm | |
| Module | 320×160 | |||
| Resolution Dot | 256×128 | 208×104 | 172×86 | |
| Surface Treatment | Matt COB | |||
| Panel Size | 640*480*59 | |||
| Panel Weight | 5.8kg | |||
| Panel Resolution (dot) | 512×384 | 416×312 | 344×258 | |
| Pixel Density(dot/m') | 640,000 | 422,500 | 288,906 | |
| Circuit Design | Common cathode circuit | |||
| Flash Correction Storage | Applicable | |||
| Brightness of White Balance | Standard 600nits | |||
| Refresh Rate | 1920-3840Hz | |||
| Contrast Ratio | 10000: 1 (Condition without lighting | |||
| Color Temperature | 9300K (Standard) | |||
| Viewing Angle | 160° | |||
| Input Voltage | AC 100~240V 50/60Hz | |||
| Max. Power Consumption (White Balance 600nit) | 840W/SQM | 740W/SQM | 690W/SQM | |
| Maintenance Way | Front Service | |||
| IP level of PCB serface | IP54 (Washable by clean water) | |||
| Operating Temperature | -10°C-+40°C/10%RH-90%RH | |||
| Stroage Temperature | -20°C-+60°C/10%RH-90%RII | |||
| Certificate | 3C, CE, CB, ETL, FCC, ROHS, CQC | |||
