Xtreme Rental LED Screen 500×1000mm XD-1000H4 Series LED Display Rental LED Wall compared with similar products on the market, it has incomparable outstanding advantages in terms of performance, quality, appearance, etc., and enjoys a good reputation in the market. Xtreme summarizes the defects of past products, and continuously improves them. The specifications of Xtreme Rental LED Screen 500×100mm XD-1000H4 Series LED Display Rental LED Wall can be customized according to your needs.
High-quality Indoor /Outdoor 500×1000mm Rental LED Display XD-1000H4 Series LED Board
● Integrated power design saves time
● Double quick lock design
● More durable, single operation
● Quick installation and maintenance
● Modular design of power control
● No wire is needed to connect
● The cabinet is light and thin
● Support arc installation
● Same HUB could using all kinds of pixel
● Wide viewing angle, no reflection
$279.13 – $554.40
| Pixel Pitch (mm) | P3.91 | P4.81 |
| Model | XD1000H4-OP3.91 | XD1000H4-OP4.81 |
| Pixel Configuration | SMD1921 | SMD1921 |
| Density (Pixels/㎡) | 65,536 | 43,264 |
| Module Resolution (Pixel) | 64x64 | 52x52 |
| Module Size (mm) | 250x250 | 250x250 |
| Driving Mode (Duty) | 1/16 | 1/13 |
| Cabinet Size (mm) | 500x500 | 500x500 |
| Cabinet Weight (KG) | 7 | 7 |
| Brightness (CD/㎡) | ≥6,000 | ≥6,000 |
| Viewing Angle (°) | 140 | 140 |
| Gray Grade (Bits) | 14 | 14 |
| Operation Power | AC100-240V 50-60Hz | AC100-240V 50-60Hz |
| Max. Power Consumption (W/㎡) | 720 | 560 |
| Avg. Power Consumption (W/㎡) | 240 | 190 |
| Frame Frequency (Hz) | ≥60 | ≥60 |
| Refresh Frequency (Hz) | ≥3,840 | ≥3,840 |
| Working Temperature (ºC) | -20～+60 | -20～+60 |
| Lifetime (Hours) | 100,000 | 100,000 |
| Protection Grade | IP65(front), IP54(rear) | IP65(front), IP54(rear) |
| Pixel Pitch (mm) | P2.6 | P2.97 | P3.91 |
| Model | XD1000H4-iP2.6 | XD1000H4-iP2.97 | XD1000H4-iP3.91 |
| Pixel Configuration | SMD1515 | SMD2121 | SMD2020 |
| Density (Pixels/㎡) | 147,928 | 112,896 | 65,536 |
| Module Resolution (Pixel) | 96x96 | 84x84 | 64x64 |
| Module Size (mm) | 250x250 | 250x250 | 250x250 |
| Driving Mode (Duty) | 1/32 | 1/28 | 1/16 |
| Cabinet Size (mm) | 500x500 | 500x500 | 500x500 |
| Cabinet Weight (KG) | 6.5 | 6.5 | 6.5 |
| Brightness (CD/㎡) | ≥1200 | ≥1,000 | ≥1,200 |
| Viewing Angle (°) | 140 | 140 | 140 |
| Gray Grade (Bits) | 14 | 14 | 14 |
| Operation Power | AC100-240V 50-60Hz | AC100-240V 50-60Hz | AC100-240V 50-60Hz |
| Max. Power Consumption (W/㎡) | 480 | 480 | 576 |
| Avg. Power Consumption (W/㎡) | 160 | 160 | 192 |
| Frame Frequency (Hz) | ≥60 | ≥60 | ≥60 |
| Refresh Frequency (Hz) | ≥3,840 | ≥3,840 | ≥3,840 |
| Working Temperature (ºC) | -20～+60 | -20～+60 | -20～+60 |
| Lifetime (Hours) | 100,000 | 100,000 | 100,000 |
| Protection Grade | IP31 | IP31 | IP31 |
