XD-250WH1 Indoor Wall LED Display

XD-250WH1 Indoor Wall LED Display

XD-250WH1 is suitable for home theaters, ultra-thin small-pitch LED walls for shops, front maintenance design,
 wireless connection between modules and cabinets, and multiple sizes for selection.

Front Service

XD-250WH1 LED video wall does not require rear maintenance access, saving installation space and structure costs.

Light and Thin cabinet

The ultra-thin LED cabinet does not require any structure, and the thickness is only 31mm, which is thinner than other wallpaper screens.

Wireless Connection

LED module data and power input plug-and-play design, no need for additional DC power lines and cables, easy to install, save trouble and effort.

More Size Options

The screen size can be customized according to the 250x250mm module: 500x250mm; 750x250mm;
1000x250mm,a variety of sizes to meet your screen size needs.

Wall Mounted

XD-250WH1 LED screen is mounted on the wall without any other structure and is easy to install.

Indoor Application

XD-250WH1 wall LED displays have a wide range of application scenarios in indoor applications, including home
 theaters and indoor advertising screens in stores.

High Definition Display

In indoor applications such as home entertainment and commercial display, the high contrast ratio and high refresh
 rate can also bring users more realistic and vivid visual effects.

XD250WH1 Indoor Wallpaper Front Service LED Display Parameter

Pixel Pitch (mm)P1.95P1.95P1.95P2.6P2.6P2.6
ModelXD-250WH1-P1.95XD-250WH1-P1.95XD-250WH1-P1.95XD-250WH1-P2.6XD-250WH1-P2.6XD-250WH1-P2.6
Pixel ConfigurationSMD1515SMD1515SMD1515SMD1515SMD1515SMD1515
Density (Pixels/㎡)262,144262,144262,144145,456145,456145,456
Module Resolution (Pixel)128x128128x128128x12896x9696x9696x96
Module Size (mm)250x250250x250250x250250x250250x250250x250
Driving Mode (Duty)1/321/321/321/321/321/32
Cabinet Size (mm)500x250750x2501000x250500x250750x2501000x250
Cabinet Weight (KG)468468
Brightness (CD/㎡)750750750750750750
Viewing Angle (°)140140140140140140
Gray Grade (Bits)141414141414
Operation PowerAC100-240V 50-60HzAC100-240V 50-60HzAC100-240V 50-60HzAC100-240V 50-60HzAC100-240V 50-60HzAC100-240V 50-60Hz
Max. Power Consumption (W/㎡)480480480480480480
Avg. Power Consumption (W/㎡)160160160160160160
Frame Frequency (Hz)≥60≥60≥60≥60≥60≥60
Refresh Frequency (Hz)384038403840384038403840
Working Temperature (ºC)-20~+60-20~+60-20~+60-20~+60-20~+60-20~+60
Lifetime (Hours)100,000100,00100,00100,00100,00100,00
Protection GradeIP31IP31IP31IP31IP31IP31

*Remark:The XD-250WH1 series is available in 3 sizes
(500x250mm / 750x250mm / 1000x250mm)
